| Structural Parameters | |
| Dimensions | 156mm(L) x 76mm(W) x 26mm(D) |
| Display | 4 inch IPS 480*800 px Multi-point capacitive touch |
| Battery | Rechargeable Li-polymer 3.7V 4000mAh/4200mAh |
| Weight | <500g |
| Keypad | 13pcs soft silicon keys |
| Performance Parameters | |
| OS | Android 7.0 |
| CPU | ARM CORTEX-A53 64bit Quad-Core 1.3G |
| Storage | 2G RAM + 16G Flash (Supports Micro SD up to 32G) |
| Data Communication | |
| WiFi | IEEE802.11 a/b/g/n |
| 4G LTE | FDD-LTE (B1,B3), TDD-LTE (B38,B39,B40,B41) |
| Bluetooth | v2.0+EDR / 3.0+HS / 4.1+HS (5-10m) |
| Collection Modules | |
| 1D Laser (Optional) | Symbol 955, Honeywell N4313 |
| 2D CMOS (Optional) | Honeywell N6603, NewLand 3096 |
| RFID (Optional) | LF (125kHz/134kHz) / HF (13.56MHz) / NFC |
| Environment | |
| Operating Temp | -20°C to 50°C |
| Drop Spec | 1.5m drop to cement (6 sides) |
| Sealing Grade | IP65/IP66 |
Equipped with a 64-bit quad-core 1.3GHz processor and Android 7.0, the device offers perfect compatibility and high efficiency for demanding industrial applications.
Fully supports 1D and 2D barcode scanning with high precision, alongside optional NFC/RFID modules for versatile data collection.
Designed for harsh environments, the IP66 rated body is waterproof, dustproof, and can withstand repeated drops from 1.2m and 1000 tumbles.
Supports full-band 4G LTE, dual-band WiFi, and Bluetooth, ensuring real-time data synchronization with your backend systems.
Yes, it features high-performance 1D/2D laser and CMOS scanners (optional) capable of reading standard barcodes and QR codes.
The device comes with a high-capacity 4200mAh Li-ion battery, designed to meet critical requirements for long shifts.
Absolutely. It has an IP66 protection grade, making it waterproof and dustproof. It also withstands drops from up to 1.5m onto cement floors.
It supports 4G LTE (FDD/TDD), 3G WCDMA, 2G GSM, dual-band WiFi (802.11 a/b/g/n), Bluetooth 4.1, and GPS/A-GPS.
Yes, the operating temperature range is -20°C to 50°C, making it suitable for both cold storage and outdoor warehouse environments.
It runs on a highly optimized Android 7.0 (Safedroid OS), providing a familiar interface and compatibility with modern APPs.
